Skip to content CD7 is a multifunctional rail-mounted module for control, indication, and fault signaling in AC/DC systems up to 230V, 50/60Hz. It supports indicator lights, illuminated buttons, and buzzers with optional button control.
Standard: IEC/EN 60947-5-1
| CD7 | – | D | G | 230V |
| Model | Function | Colour | Voltage | |
| Rail signal module | D:Indicator | G:Green R:Red Y:Yellow B:Blue W:White GR:Green+Red | 380V 230V 110V 24V 12V 6.3V |
| Standard | Data |
| Rated working voltage (AC/DC) | 6.3V,12V,24V,110V,230V,380V |
| Rated working current | ≤20mA |
| Colour | G:Green R:Red Y:Yellow B:Blue W:White GR:Green+Red |
| Working life | ≥30000h |
| Connecting wire | 20 |
| Tightening torque | 0.8N.m |
| Protection grade | IP20 |
| Operation temperature | -5°C~+40°C;(with daily average≤35°C |
| Altitude | ≤2000m |
| Installation category | II,III |
| Pollution degree | 2 |
| Installation method | DIN rail TH35-7.5 |
